Three-phase Inverter

The three-phase, two-way MOD series is suitable for small and medium-sized domestic systems. Beautiful appearance, compact structure, simple installation, silent, maintenance-free.

Send Inquiry

Description

Products Description

- Maximum DC voltage 1100V
- DC overmatch 1.5 times
- String current 13A
- 110% long term overload
- AC/DC secondary lightning protection
- OLED display, touch keys
- Natural cooling, no noise, maintenance-free
- Flexible monitoring mode, intelligent one-touch diagnosis

MOD 3000-6000 TL3-X	MOD 3000TL3-X	MOD 4000TL3-X	MOD 5000TL3-X	MOD 6000TL3-X
Input data (DC)
Max. DC input power	4500W	6000W	6500W	7800W
Output data (AC)
Rated AC output power	3000W	4000W	5000W	6000W
Maximum AC output power	3300VA	4400VA	5500VA	6600VA
Maximum AC output current	5.0A	6.7A	8.3A	10.0A
Efficiency
Maximum efficiency	98.3%	98.3%	98.3%	98.3%
MPPT efficiency	99.9%	99.9%	99.9%	99.9%
General data
Dimensions (width, height, thickness) mm	425/387/138	425/287/138	425/387/138	425/387/138
CQC,CE,VDE 0126-1-1,VDE-AR-N4105,EN50438,CEI 0-21, AS4777

MOD 12-15KTL3-X	MOD 8KTL3-X	MOD 9KTL3-X	MOD 10KTL3-X	MOD 11KTL3-X
Input data (DC)
Max. DC input power	12000W	13500W	15000W	15000W
Output data (AC)
Rated AC output power	8000W	9000W	10000W	11000W
Maximum AC output power	8800VA	9900VA	11000VA	11000VA
Maximum AC output current	13.3VA	15.0VA	16.7VA	18.3VA
Efficiency
Maximum efficiency	98.6%	98.6%	98.6%	98.6%
MPPT efficiency	99.9%	99.9%	99.9%	99.9%
General data
Dimensions (width, height, thickness) mm	425/387/138	425/287/178	425/387/178	425/387/178
CQC,CE,VDE 0126-1-1,VDE-AR-N4105,EN50438,CEI 0-21, AS4777
