Carport Solar Panel Supporting Structure
Material:Aluminum 6005-T5
Installation Angle:5°-15°
Installation Site:Open field
Color:Natural
Standard:AS/NZS 1170/SGS/ISO9001
Wind Load:60m/s
Snow Load:1.4KN/m2
Description
Technical Specifications
| Feature | Details |
| Product Category | Solar Panel Supporting Structure (4-Post Carport) |
| Material | High-Strength Q235B / Q345B Carbon Steel |
| Surface Treatment | Hot-Dip Galvanized to ISO 1461 Standards |
| Foundation Type | Concrete Foundation with M20/M24 Anchor Bolts |
| Component List | Columns, Longitudinal Beams, Rails, Clamps, and Fasteners |
| Angle | Fixed (Standard 5°, customizable) |
| Hardware | SUS304 Stainless Steel & Dacromet Coated Steel |
Key Product Features
Four-Post Rigid Architecture: The symmetric four-post design ensures superior structural balance and load distribution, making it an incredibly stable solar panel supporting structure for areas with high environmental stress.
High-Clearance Utility: Engineered with a standard height that accommodates SUVs, vans, and light trucks, ensuring that energy generation does not interfere with daily vehicle operations.
Advanced Corrosion Resistance: All steel components are treated with a heavy-duty Hot-Dip Galvanized coating (≥80μm) to prevent rust and degradation in outdoor environments for over 25 years.
Modular & Pre-Engineered: The system arrives as a complete kit with precision-drilled components, including main columns, longitudinal beams, and rail supports, for a fast "bolt-together" installation.
Weather-Resistant Protection: Beyond energy production, the robust solar panel supporting structure acts as a durable shield, protecting vehicles from direct UV exposure, heavy rain, and snow.
Bill of Materials (BOM) & Structural Components
Our solar panel supporting structure is built with high-precision components to ensure long-term mechanical integrity:
Main Supports: Heavy-duty steel columns provide the primary vertical lift.
Longitudinal Beams: Reinforced beams span the four posts to create a rigid horizontal frame.
Solar Rails: Aluminum or steel rails mounted across the beams to support the PV modules.
Hardware Kit: Includes M16/M14 bolts, mid-clamps, and end-clamps for secure panel fastening.
FAQ
Q: What are the benefits of a four-post solar panel supporting structure over a two-post design?
A: The four-post design offers significantly higher structural stability and weight-bearing capacity. It is less susceptible to vibration in high winds and is the preferred choice for larger carports or regions with heavy snow loads where a more rigid foundation is required.
Q: Is the four-post carport customizable for different vehicle counts?
A: Yes. While the standard unit covers two parking spaces, the solar panel supporting structure is modular. We can provide engineering layouts to link multiple units together for large commercial parking lots.
Q: How is the structure anchored to the ground?
A: The system uses heavy-duty base plates bolted into pre-cast concrete footings using high-strength anchor bolts. This ensures that the solar panel supporting structure remains securely grounded even under extreme weather conditions.
Transform your parking space into a powerful energy asset. Contact us for the full technical data sheet and a customized quote for your Solar Panel Supporting Structure.
