Flexible Power Solar Wire Roll Pv Cable
Product name:PV Cable Solar DC Panel Power Cable
Color:Customized
Conductor:Tinned Copper
Certificate:TUV
Core:1-2 Core
Rated voltage:0.6/1KV AC 1500V DC
Description
2.Which is designed for connecting photovoltaic system components inside and outside of buildings and equipment with high mechanical requirements and extreme weather conditions.
3.It has the characteristics of UV resistance, wears resistance, and aging resistance, and the service life is more than
25 years.
|
No. Of cores x Construction （mm2） |
Conductor Construction （n / mm） |
Conductor No./mm |
Insul.Thick. (mm) |
Current Aarring Capacity (A) |
|
1x1.5 |
30/0.25 |
1.58 |
4.9 |
30 |
|
1x2.5 |
50/0.256 |
2.06 |
5.45 |
41 |
|
1x4.0 |
56/0.3 |
2.58 |
6.15 |
55 |
|
1x6 |
84/0.3 |
3.15 |
7.15 |
70 |
|
1x10 |
142/0.3 |
4.0 |
9.05 |
98 |
|
1x16 |
228/0.3 |
5.7 |
10.2 |
132 |
|
1x25 |
361/0.3 |
6.8 |
12.0 |
176 |
|
1x35 |
494/0.3 |
8.8 |
13.8 |
218 |
|
1x50 |
418/0.39 |
10.0 |
16.0 |
280 |
|
1x70 |
589/0.39 |
11.8 |
18.4 |
350 |
|
1x95 |
798/0.39 |
13.8 |
21.3 |
410 |
