Solar Home System On Grid

Name: Solar Home System On Grid Manufacturers and Suppliers China - Factory Price - Wanhos
Brand: Wanhos
SKU: 120835804

Place of Origin: Fujian,China
Solar Panel Type: Monocrystalline Silicon
Output Voltage(V): 220VAC
Certificate: CE
Keyword: 500 watt power inverter
System type: off grid system
Solar powr System-Panel+controller,inverter+battery
E-mail: sales04@wanhos.com
WhatsApp: 008613696955256

Send Inquiry

Description

Solar Home System On Grid System 20KW

Equipments&Details

20KW ON GRID SOALR POWER SYSTEM DESIGN
Item	Model	Description	Quantity
1	390M-72	Mono 390W solar panel	52pcs
2	Growatt 20000TL3-S	20KW Three Phase inverter	1 set
3	WIFI Module	Monitoring device	1 pc
4	PV Cables	4mm2 PV cables	800m
5	PV connector	Rated voltage:1500V	26Pairs
6	Mounting brackets	Customized for roof or ground	1 set
7	DC combiner box	SPD,Breaker,lighting protection	1 set

Solar Panels

> 25 years Warranty
> Highest conversion efficiency of 17%
> Anti-reflective and anti-soiling surface power
  loss from dirt and dust
> Excellent mechanical load resistance
> PID Resistant,High salt and ammonia resistance

Grid Tie Inverters

> 5 years standard warranty> Max.Efficiency 99.6%,European efficiency 99%;> Integrated DC switch for added safety protection;
> Power factor continuously adjustable
>Transformer-less design and high power density,
  off lighter and more convenient installation
> Flexible communication connection,support RF WIFI

Mounting structure

> Residential Roof(Pitched Roof)
> Commercial Roof(Flat roof&workshop roof)
> Ground Solar Mounting system
> Vertical wall solar mounting system
> All aluminum structure solar mounting system
> Car parking solar mounting system

Accessories

> PV Cable 4mm2 6mm2
> AC Cable
> DC Switches
> AC Breaker
> AC/DC Combine box

Advantages of Grid-Tied Systems:

1. Save more money with net metering
Your solar panels will often generate more electricity than what you are capable of consuming. With net metering, homeowners can put this excess electricity onto the utility grid instead of storing it themselves with batteries.
2. The utility grid is a virtual battery
The electric power grid is in many ways also a battery, without the need for maintenance or replacements, and with much better efficiency rates. In other words, more electricity goes to waste with conventional battery systems.
