270w 275w 280w Poly Solar Panel

Place of origin:Fujian,China
Application:solar mounting
Size:1960*992*40mm
Solar cell: Poly 156*156 Cell
Warranty:20 years

Send Inquiry

Description

Customized 270w 275w 280w Poly Solar Panel free sample and its quotation and pricelist consultation, China Solar Energy System manufacturers and suppliers，Welcome to buy our products.

270w 275w 280w poly solar panel

solar panel (2)

photobank (4)

Moduel	TS-72-365M	TS-72-370M	TS-72-375M
Maximum Power at STC (Pmax)	365W	370 W	375W
Optimum Operating Voltage (Vmp)	39.5 V	39.7 V	39.9 V
Optimum Operating Current (Imp)	9.24 A	9.32 A	9.40 A
Open Circuit Voltage(Voc)	47.9 V	48.1 V	48.3 V
Short Circuit Current(Isc)	9.71 A	9.78 A	9.85 A
Module Efficiency	18.8%	19.0%	19.3%
Operating Module Temperature	-40 °C to +85 °C
Maximum System Voltage	1000/1500 V DC (IEC)
Maximum Series Fuse Rating	20 A
Power Tolerance	0~+5W
Standard Test Condition(STC)	lrradiance 1000 W/m 2 , module temperature 25 °C, AM=1.5;Tolerances of Pmax, Voc and Isc are all within +/- 5%.

photobank (32)

Moduel	TS-60-275P	TS-60-280P	TS-60-285P
Maximum Power at STC (Pmax)	275W	280W	285W
Optimum Operating Voltage (Vmp)	31.4V	31.6 V	31.7 V
Optimum Operating Current (Imp)	8.76 A	8.86 A	9.00 A
Open Circuit Voltage(Voc)	38.1V	38.5 V	38.9 V
Short Circuit Current(Isc)	9.27A	9.38 A	9.46A
Module Efficiency	16.8%	17.1%	17.4%
Operating Module Temperature	-40 °C to +85 °C
Maximum System Voltage	1000/1500 V DC (IEC)
Maximum Series Fuse Rating	20 A
Power Tolerance	0~+5W
Standard Test Condition(STC)	lrradiance 1000 W/m 2 , module temperature 25 °C, AM=1.5;Tolerances of Pmax, Voc and Isc are all within +/- 5%.
