Tile Roof Mounting Brackets For Solar Panels
Material: Aluminum 6005-T5 or Q235
Install Angle: 0 to 60 degree
Wind Load:<60m/s
Snow Load: <1.4KN/m2
E-mail: sales04@wanhos.com
WhatsApp: 008613696955256
Description
Tile Roof Mounting Brackets For Solar Panels are used to support the rail. They have adjustable and fixed
type for your choices. Different type roof hook can meet different tile roofs. Varied roof hooks or brackets with tilt
-in modules ensure easy and quick installation.
| Installation site | Pitched roof |
| Tile angle | Flushed to roof |
| Building height | Below 20m |
| Max wind load | 42 m/s |
| Max snow load | 0.5 KN/M2 |
| Material | Al6005-T5&SUS304 |
| Color | Natural |
| Treatment | Anodizing |
| Warranty | 12 years |
| Service life | 25 years |
Features: 1.Module design, easy installation.
2.Stable structure, mounted securely.
3.Aluminium alloy and stainless steel, long service life.
4.Various hook designs, fit with all kinds of tiles.
Advantage as follow:
1. Tile Hook: several typesaccording to your tile direction.
2. Simple Components: Only 3 components !
3. Most Ports are preassembled: save 50% labor cost
4. Lower and Competitive price.
5. Rust-resistance.
Specification
| lnstall Site | Low profile roof of open field |
| Tilt Angle | 10deg-60deg |
| Building Height | Up to 20m |
| Max Wind Speed | Up to 60m/s |
| Snow Load | Up to1.4KN/m2 |
| standards | AS/NZS 1170 & DIN 1055 & Other |
| Material | Aluminum alloy & Stainless steel |
| Color | Natural |
| Anti-corrosive | Anodized |
| Warranty | Ten years warranty |
| Duratiom | More than 20 years |
|
 |
In order to help you get the right system, please offer the following necessary info.:
1) Panel dimension. ____(1640*992*40mm, 250w).
2) Panel quantity.____(Pieces or total power)
3) Installation Angle. ____(5°,10°, 15° etc)
4) Planned solar array.____(Horizontal,4x20pcs)
5) Wind speed____ m/s,and snow load____KN/m2.
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
