Solar Panel Mounting System For Metal Roof
Metal roof- trapazoidal profile Suitable for corrugated metal roofs with trapezoidal roof profile solar panels arranged in protrait mode Mounting structure components include: Slotted rails End and mid clamps Rubber gasket Nuts and bolts Above components are made out of anodized all rails...
Description
Metal roof- trapazoidal profile
Suitable for corrugated metal roofs with trapezoidal roof profile solar panels arranged in protrait mode
Mounting structure components include:
Slotted rails
End and mid clamps
Rubber gasket
Nuts and bolts
Above components are made out of anodized all rails riveted to metal roof with self-drilling screws
Easy installation metal roof aluminum slotted rail for solar panel
Application
Suitable for corrugated metal roofs with trapezoidal roof profile-solar panels arranged in portrait mode
Customized ballasted mounting system
Racking Support sample and its quotation and pricelist consultation, China Pile Ground Mounting System manufacturers and suppliers,Welcome to buy our products.
Specification
| lnstallation Site | Standing Seam Tin Metal Roof |
| Max Wind Speed | 60 m/s |
| Snow Load | 1.4KN/m2 |
| Material | 6005-T5 Aluminum Body, Stainless Fastener |
| Certification | ISO, SGS, Aluminum testing report |
| Color | Natural |
| Anti-corrosive | Anodized, Electrophoresis |
| Warranty | 10 years warranty, life time more than 25 years |
| Packing | For Small Parts | Plastic bag, Box, Wooden Pallet. |
| For Big Parts | Steel Pallet, Wooden Pallet | |
| Delivery | By Sea | Delivery from Xiamen Seaport |
| By Air | Departure from Xiamen Airport | |
| By Express | By TNT/DHL | |
| Payment | TT | 30%T/T in advance, paid the balance before shipment |
| 30%T/T in advance, paid the balance against BL | ||
| L/C | above 50,000 usd, we can accept L/C at sight | |
| West Union | Amount lower than 5000usd | |
| Delivery Time | 5~15days after receiving payment | |
| Nessary info. for us to design and quote |
| What is your pv panels dimension?___mm Length x___mm Width x__mm Thickness |
| How many panel are you going to mount? _______Nos. |
| What's the tilt angle?____degree |
| What is your planned pv assmebly block? ________Nos. in a row |
| How is weather there,such as wind speed and snow load? |
| ___m/s anit-wind speed and____KN/m2 snow load. |
