DIY Solar Panels Supports Frame

Name: DIY Solar Panels Supports Frame
Brand: Wanhos
SKU: 27342084

TRIANGLE SYSTEM (10-45°) The Triangle System is suitable for nearly all types of flat roofs. In most cases, it is used for special constructions, since the construction triangles allow flexible connections and elevations. Individually customisable elevation angle Universal module orientation...

Send Inquiry

Description

Customized DIY Solar Panels Supports Frame free sample and its quotation and pricelist consultation, China Roof Mounting System manufacturers and suppliers，Welcome to buy our products.

TRIANGLE SYSTEM (10-45°)

The Triangle System is suitable for nearly all types of flat roofs. In most cases, it is used for special constructions, since the construction triangles allow flexible connections and elevations.

Individually customisable elevation angle

Universal module orientation

High flexibility and custom solutions

Variable use of framed and frameless PV modules on flat roofs of both old and new buildings, in which the base triangles are either mounted with ballast blocks or directly with hanger screws, on system carriers or trapezoidal sheet metal rails. For the optimum irradiation angle, the Triangle is available as standard with a pitch of 10°/15°/20°/25°/30°/35°/40°/45° (other angles on request)!

Fast installation of the substructure thanks to a high degree of pre-assembly, new one-click technology and a detailed installation recommendation.

Height-adjustable module clamps and end clamps allow for maximum flexibility when mounting framed modules from 1.10 to 2.05 inch thick (28 - 52 mm). We can also provide certified laminate clamps for frameless modules.

The use of our telescoping mounting-rail splices enable the equipment to be positioned accurately without the need for cutting.Variable system height capability enables a level photovoltaic array on uneven roof surfaces. The base triangles can be mounted directly to the roof structure or attached to a variety of rails to span between appropriate rafters or purlins. If it is not possible to penetrate the roof, the structure can be fixed directly onto profiled or corrugated roofing using the appropriate bracket. Direct assembly onto ballasts is also possible.

If required, Wanhos can provide structural design services for the mounting structure in compliance with the 2006 International Building Code.

All major components are made of aluminum and stainless steel. High corrosion resistance ensures a maximum service life and all components are recyclable.
