Ground Mount Solar Mounting
Material: Aluminum Alloy
Surface treatment: Anodized
Standards:ASNZS1170&ISO9001&SGS&TUV&Other
Module Type: Framed or frameless
Installation site: Open Field
Max Wind Speed: Up to 60m/s
Max Snow Load: Up to 1.4KN/m2
Warranty: 10 Years
Wanhos Ground Mount Systems: C-Steel & AL6005-T5 structures for harsh terrains. 70m/s wind & 1.8KN/m² snow load resistant. TUV/CE certified. Free CAD designs. 15-year warranty. Export documents included.
Description
Products Description
Ground Mount Solar Mounting Systems - Heavy-Duty C-Steel Solutions | Wanhos Solar
Wanhos Solar's ground mount systems combine AL6005-T5 aluminum rails with carbon steel (C-Steel) frames for maximum durability. Engineered to withstand 70m/s winds and 1.8KN/m² snow loads, our structures feature triple-layer anti-corrosion treatment for 20+ year lifespans. Ideal for rocky, sandy, or sloped terrains (≤25° gradient).
| Parameter | C-Steel Version | Aluminum Version |
|---|---|---|
| Frame Material | Q235 Carbon Steel | AL6005-T5 (EN 573-3) |
| Corrosion Proof | 120μm Epoxy Powder Coating | Chromium-free Anodizing |
| Max Height | 4.5m | 3.5m |
| Tilt Range | 10°-60° (Hydraulic Adjust) | 15°-60° (Manual) |
| Wind Resistance | 70m/s (IEC 61400-2 Class I) | 60m/s |
| Snow Load | 1.8KN/m² | 1.4KN/m² |
| Certifications | TUV, CE, UL 3703 | TUV, CE, AS/NZS 1170 |
Core Advantages
Industrial-Grade Construction
3.0mm C-Steel frames with robotic welding (KUKA KR 20)
Hot-dip galvanized bolts (ISO 1461)
Zero Terrain Limitations
5 foundation types: Helical screws / Concrete piles / Ballast / Driven piles / Rock anchors
No leveling needed for ≤25° slopes
Rapid Installation
Pre-assembled modules: 2.5MW/week crew output
Tool-free rail clamping
Trade Terms
| Service | Detail |
|---|---|
| Lead Time | 18 days (12 days expedited +8%) |
| Payment | 30% TT / Alibaba / L/C at sight |
| MOQ | 1MW (≈2,800 sets) |
| Container Load | 550 sets per 40HQ |
| Samples | Free C-Steel bracket (DHL 4 days) |
Why Global EPCs Choose Us
780+ Projects in 30 Countries:
Saudi desert plants (58MW, 50°C)
Norwegian snowfields (22MW, -35°C)
Smart Customization:
Free site BIM modeling (provide terrain scans)
Risk Mitigation:
15-year structural warranty
On-demand wind load reports (ASCE 7-22)
FAQ of Wanhos ground mount solar mounting
Q: How protect C-Steel from rust in coastal areas?
A: Triple coating: Zinc phosphate + Epoxy primer + Polyurethane topcoat (3,000hrs salt spray passed).
Q: Minimum soil depth for screw foundations?
A: 1.2m (tested in sandy/rocky soils via ISO 22476-1).
Q: Can I mix C-Steel and aluminum components?
A: Yes. Our isolation pads prevent galvanic corrosion (ISO 8044 compliant).
Q: Warranty for paint peeling?
A: 10-year coating guarantee (ISO 12944-C5M standard).
